Eaton Moeller – residual current circuit breaker – อุปกรณ์ป้องกันไฟดูด พร้อมเซอร์กิตเบรคเกอร์ในตัว – PXK-B16/1N/003-A [RCBO-Type A]

Residual-Current Circuit Breaker with Overcurrent Protection. RCBO

MODEL : PXK-B16/1N/003-A
LENGTH/DEPTH : 80 mm
PRODUCT HEIGHT : 75 mm
PRODUCT WIDTH : 35 mm
PRODUCT WEIGHT : 0.193 kg
CERTIFICATIONS : CE
AMPERAGE RATING : 16 A
VOLTAGE RATING : 240 V – 240 V
SURGE CURRENT CAPACITY : 0.25 kA
VOLTAGE TYPE : AC
WIDTH IN NUMBER OF MODULAR SPACINGS : 2
RATED CURRENT : 16 A
RATED OPERATIONAL CURRENT FOR SPECIFIED
HEAT DISSIPATION (IN) :16 A
RATED SWITCHING CAPACITY (IEC/EN 61009) : 10 kA
RATED OPERATIONAL VOLTAGE (UE) – MAX : 240 V
RATED INSULATION VOLTAGE (UI) : 440 V
RATED SWITCHING CAPACITY : 10 kA
NUMBER OF POLES : Single-pole + N
DEGREE OF PROTECTION : IP20
LEAKAGE CURRENT TYPE : A
RELEASE CHARACTERISTIC : B
