PLASTIM – Hygrostat – PHG02 (110-250 V AC)

Models : PHG02
Power Supply : 110-250 V AC
Setting Range : 10-90 % RH
Colour Of Potentiometer : Black
Current : (10-5) A
Differential : %5, max. %10
Sensor Type : Polyamide Ribbon
Electrical Connections : 3-Pole Terminal
Electrical Section Wires : From 0.75 mm² to 4.0 mm²
Operating Temperature : +10/+60 °C
Storage Temperature : +10/+60 °C
Protection Degree : IP20
Colour : RAL7035
Mounting : Clip for mounting on DIN Rail 35mm
Dimensions YxGxD : 94x54x56 mm
Weight : 180 g
