EATON – 20DILE, 2 pole, 2 N/O, Auxiliary contact module, Front fixing, Screw terminals, DILE(E)M, DILER

Auxiliary contact module, 2 pole, 2 N/O, Front fixing, Screw terminals,

DILE(E)M, DILER

รหัสสินค้า: 20DILE หมวดหมู่: EATON CONTACTOR, แมกเนติกและรีเลย์

คำอธิบาย
ข้อมูลเพิ่มเติม

General specifications

Part no. : 20DILE
Product Length/Depth : 36 millimetre
Product height : 32 millimetre
Product width : 45 millimetre
Product weight : 0.03 kilogram
Product Tradename : DILE
Product Type : Accessory
Number of poles : Two-pole
Functions : For standard applications
Degree of protection : IP20
Rated impulse withstand voltage (Uimp) : 6000 V AC
Screw size : M3.5, Terminal screw
Tightening torque : 1.2 Nm, Screw terminals
Rated insulation voltage (Ui) : 690 V
Rated operational voltage (Ue) at AC – max : 600 V
Safe isolation : 300 V AC, Between coil and auxiliary contacts, According to EN 61140
300 V AC, Between auxiliary contacts, According to EN 61140

น้ำหนัก	0.03 กรัม
ขนาด	3 × 3 × 4 เซนติเมตร
