INPUT SPECIFICATIONS
– Rated Input Voltage : 115 /230 VAC
– AC Input Voltage Range : 90 to 264
– DC Input Voltage Range : 120 to 375
– Line Frequency-Max. : 63 Hz
– Line Frequency-Min. : 47 Hz
– Max. Inrush Current (Vi: 115 VAC) : 25 A
– Max. Inrush Current (Vi: 230 VAC) : 50 A
– Rated Input Current -Typ. (Vi : 115 VAC) : 4.9 A
– Rated Input Current -Typ. (Vi : 230 VAC) : 2.5 A
– Rated Input Current -Max. (Vi : 115 VAC) : 7 A
– Rated Input Current -Max. (Vi : 230 VAC) : 3.5 A
– Power Dissipation (Vi: 230 VAC, Io norm) : 63 W
– Leakage Current (Input-Output) : 0.25 mA
OUTPUT SPECIFICATIONS
– Output Voltage 24 VDC
– Output Current 20 A
– Output Voltage Accuracy (Adjusted before
– shipment) : 0 to +1 %
– Minimum Load : 0 %
– Line Regulation : +/- 0.5 %
– Load Regulation : Single Mode +/- 1 %
– Load Regulation : Parallel Mode +/- 5 %
– Output Voltage Trim Range : 22.5 to 28.5 VDC
