Connectwell – Screw Clamp Feedthrough Terminal Block – CTS10U

Technical Data
Short-Time Withstand Current : 1.2 kA
Type of Connection : Screw Clamp
Wire Entry Orientation : Side
Operating Temperature Range : -40 to +105
Number of Levels : 1
Number of Connections : 2
Rated Voltage (IEC) : 1000 V
Rated Current (IEC) : 57 A
Tightening Torque (IEC) : 1.2 Nm
Rated Voltage (UL/CSA) : 600 V
Rated Current (UL/CSA) : 65 A
Tightening Torque (UL/CSA) : 14 lb-in
Mounting Possibility : DIN 32/DIN 35/DIN 35-15 Rail
Internally Shorted : No
Screw Size : M4
Operated by : Screwdriver
Rated Surge Voltage : 8 kV
Overvoltage Category : III
Pollution Degree : 3

Ordering Information
Standard Pack : 100 Nos
Weight (Excluding Packaging) : 16.9 gms
Weight (Including Packaging) : 17.7 gms

Material Details
Material Group : 1
Housing Material : Polyamide
Flammability Class According to UL 94 : V2
Colour : Grey
Comparative Tracking Index : 600

Dimensions
Width (Thickness) : 10 mm
Length : 43 mm
Height with DIN 35 x 7.5 mm rail : 47.8 mm
Height with DIN 35 x 15 mm rail : 55.5 mm
Height with DIN 32 mm rail : 52.8 mm
